HTL-V420 Large Vertical Automatic Packaging Machine for granules
flakes
Intoduction and SCOPE OF APPLICATION
It is suitable for packaging products such as granules, flakes and
strips, such as sugar granules, potato chips, shrimp strips,
jellies, peanuts, etc. within 3000ml.
1. Using color touch screen and stable and reliable two-axis
high-precision output PLC control, bag making, metering, filling,
sealing, hitting, and cutting bags are completed in one time.
2. The air circuit control and circuit control are separated
independently, the noise is small,and the circuit is more stable.
3. The vacuum belt is used to pull the film: the film has less
resistance, the bag is formed well, and the belt is not easy to
wear.
4. Adopt double servo control to achieve high precision positioning
and accurate size.
5. With the external film release mechanism, the packaging film
installation is simpler and easier.
6. The deviation adjustment of the packaging bag can be adjusted
only on the touch screen, and the operation is simple.
7. The whole machine adopts a closed mechanism to effectively
prevent dust from entering the inside of the machine.
8. Adopt electronic weighing method, the package weight is more
accurate, and the production cost is lower.
Main Technical parameters
| Item | Content |
| Capacity | 50 bags/min,it is according to quality of wrapping and supplies |
| Accuracy | ≤±1.5% |
| Bag size | (L)80-300mm (W)50-200mm |
Max.Packing film width Film width | 420mm |
| Bag type | Pack with film, upper seal, lower seal and back seal by automatic
bag making machine. |
| Film thickness | 0.06-0.08mm, the best is 0.07-0.08mm |
| Package material | thermal composite material., like BOPP/CPP, PET/AL/PE etc |
| Air consumption | 0.8Mpa 0.5m3/min |
| Total powder | 4.745KW |
| Voltage | Four wire three phase, 380V 50HZ |
| Air compressor | Not less than 1 cube |
| Total height | 3.508 m |
Packaging and Delivery
1. Prompt deliver at the very day.
2. Sophisticated and professional logistic agent.
3. Well-trained and disciplined packing team.
4. After-sale service:. Any questions or problems after receiving
the product, please feel free to contact us. Problems would be
solved for you immediately.
Quality Guarantee
The quality of the production line will have 12 month warranty
since the installtion in the buyer's factory.
