Stable and durable fully automatic servo control KN95 mask machine
Intoduction and SCOPE OF APPLICATION
HTL-KN95 mask machine is a fully automatic high speed KN95 mask
production line newly developed by Jiangsu Haitel Machinery Co.,
Ltd., including automatic raw material delivery, automatic
conveying, cutting nose bridge, welding forming, nose bridge
filling, ear strap welding, folding, cutting Recycling and other
full-process automation, complete the entire production process
from coil raw materials to finished masks.
Equipment features
1. The whole equipment is fully automated.
2. The whole machine adopts aluminum alloy structure, which is
beautiful and firm without rust.
3. Computer PLC programming control, servo drive, high degree of
automation.
4. Automatic tension control of raw materials to ensure the balance
of raw material tension.
5. Photoelectric (optical fiber) testing materials to avoid
mistakes and reduce waste.
6. Adopt multiple sets of pneumatic components to achieve precise
control.
1． Equipment size:10050mm(L)×1500mm(W)×2200mm(H) |
2． Appearance color: International standard warm gray 1C (DB
standard color), according to this standard when no special
instructions |
3． Equipment weight:≤2800kg,
Ground bearing≤300KG/m2； |
4. Working power: Equipment380VAC±5﹪,50HZ, Rated power 9KW； |
5. Compressed air:0.5～0.7 MPa, Use flow is about20000L/min； |
6. Use environment: Temperature 10～35℃,Humidity 5-35%HR, No
flammable, corrosive gas, no dust(Cleanliness not less than
100,000) |
7. Productivity: 25-70PCS/MIN； |
8. Equipment production pass rate:99%(When the incoming materials
do not meet the requirements and the employees do not operate
properly) |
9. Equipment failure rate:2%(Refers to the fault generated by the
device itself) |
ntroduction of raw material selection
KN95 is a six-layer fabric structure, the outer layer is
skin-friendly non-woven fabric, built-in PP cotton and double-layer
electrostatic adsorption melt-blown filter element, to filter
particles with aerodynamic diameter of 0.24 ± 0.6μm (physical
diameter 0.075µm ± 0.020µm) The efficiency reaches more than 95%.
After production, it shall be sterilized by ethylene oxide and
allowed to stand for 7 days for volatilization toxicity. After
being sealed and packed, it shall be shipped out in a box.
The module mainly includes a mask feeding flattening mechanism, a
mask cutting mechanism output structure and an automatic waste
recycling mechanism.
It mainly realizes automatic feeding of ear straps, fixed cutting,
and placing the cut ear straps in the position specified by the
plane mask. The equipment automatically completes the ultrasonic
welding of the ear straps and mask.
Main electrical configuration list
| NO. | Item | Brand | Remarks |
| 1 | PLC | Siemens | |
| 2 | Touch screen | Siemens | |
| 3 | servo motor | Siemens | |
| 4 | cylinder | SMC / Japan, Kuangxin / Taiwan | |
| 5 | The electromagnetic valve | SMC / Japan, AirAsia, Kuangxin / Taiwan | |
| 6 | Ordinary speed regulating motor | Xinshengda / China | |
| 7 | Bearing | NSK / Japan, HRB / China | |
| 8 | Line rail | Siemens | |
| 9 | Optical fiber amplifier | Omron, Boye Precision, Panasonic/Japan | |
| 10 | Relay | Omron | |
| 11 | Button | Delixi | |
| 12 | Ultrasound | Shanghai Jiaocheng |
